AMNYTT AMNYTT.no 4/2026 | Page 93

Terminal marking
Web code: # 0883 Material group Description Sizes
MM-TML...
Label for terminal blocks / zack marker strips, continuous material, mounting method: adhesive, the material is cUL-certified
Various widths, material length: 8 m
Color material / ink ribbon
White / black Transparent / black
MM-TMT...
Markers for terminal blocks, continuous, mounting method: latching into universal and fl at marker grooves
Various widths, material length: 5.5 m
White / black
Conductor and cable marking
Web code: # 0884 Material group Description Sizes
MM-WML...
Cable winding labels, pre-punched, mounting method: adhesive, the material is cUL-certifi ed
Conductor / cable diameter ≥2 mm to ≤14 mm
Color material / ink ribbon
White / black
MM-WML...( EX...)...
Cable winding labels, continuous, mounting method: adhesive, the material is cUL-certifi ed
Conductor / cable diameter ≥2 mm to ≤5 mm Material length: 6.5 m
White / black Yellow / black
MM-WML-FLAG...
Cable marking fl ags, pre-punched, mounting method: adhesive, the material is cUL-certifi ed
Conductor / cable diameter ≥1 mm to ≤6 mm
White / black
MM-WMS...
Shrink sleeves, shrink rate: 3:1, continuous, mounting method: push-on; the material is cUL-certifi ed
Conductor / cable diameter ≥1.0 mm to ≤9.5 mm Material length: 1.8 m
White / black Yellow / black
MM-WMS-2...
Shrink sleeves, shrink rate: 2:1, continuous, mounting method: push-on; the material is cUL-certifi ed
Conductor / cable diameter ≥1.5 mm to ≤9.5 mm Material length: 1.8 m
White / black Yellow / black
MM-WMT...
Conductor markers, pre-punched, mounting method: push-on
Conductor / cable diameter ≥1.0 mm to ≤8.4 mm
White / black
MM-WMTB...
Cable markers, pre-punched, mounting method: cable tie mounting
Cable diameter ≥6 mm
White / black
MM-WMTB HF...
Cable markers, pre-punched, mounting method: cable tie mounting
Cable diameter ≥6 mm
White / black Yellow / black
Equipment marking
Web code: # 0885 Material group Description Sizes
Color material / ink ribbon
MM-EML...
Labels, pre-punched, mounting method: adhesive, the material is cUL-certifi ed
Various lettering fi eld sizes
White / black Yellow / black
MM-EML( EX …)...
Labels, continuous, mounting method: adhesive, the material is cUL-certifi ed
Various widths, material length: 8 m
White / black Yellow / black Silver / black Transparent / black
MM-EMLC...
Highly flexible labels, continuous, mounting method: adhesive, the material is UL-certifi ed
Various widths, material length: 6 m
White / black
MM-EMLF...
Labels, continuous, mounting method: adhesive, the material is cUL-certifi ed( only white and yellow versions)
Various widths, material length: 8 m
White / black, yellow / black, orange / black, red / white, blue / white, green / white
MM-EMT...
Markers for various marker carriers, continuous, mounting type: Push-in into marking carriers
Various widths, material length: 5.5 m
White / black
Please note: Pre-punched parts can only be processed with the THERMOMARK GO.
PHOENIX CONTACT 19
