Power grid monitoring and control |
|||||||||||||||||
The monitoring of parameters is a fundamental requirement for the efficient expansion and reliable operation of power grids. Easy confi guration, evaluation, logic operations, and communication of signals and values are absolutely essential for this. Our smartRTU allows you to easily confi gure and quickly commission remote control technology applications using a web browser and without any programming knowledge. Its modular structure means that additional devices such as shortcircuit and ground fault indicators can be integrated fl exibly, enabling a wide range of applications to be implemented. Messages concerning operating states and variables are transferred to higher-level remote control nodes or control systems in compliance with all current regulations governing information security. The signals are communicated in parallel using various protocols such as IEC 60870-5-101 / 104 or IEC 61850. |
Alongside monitoring solutions, smartRTU can also execute a wide range of( remote) control commands, from simple single-point information through to complex double commands with interlocks. For example, load switches and circuit breakers can be controlled remotely through straightforward parameterization. |
X3: ETH X2: ETH |
X9: COM X10: COM X11: COM X1: PWR 24VDC
ERROR RUN CF PWR
|
Network control center
Remote control node
Modem
WAN( Wide Area Network)
Modem
Remote control substation
|
|||||||||||||
Grid monitoring and control |
|||||||||||||||||
