XTS: New motor modules for even more production flexibility
With new motor modules, the high flexibility of the eXtended Transport System (XTS) has been
increased yet again. The straight and curved motor modules (180°) are supplemented by new
variants with a radius of 22.5°. Matching guide rails are also available for the new motor
modules. The range of applications can now be further extended:
– individual track layouts
– flexible rotary indexing table
– full circle with movers running around the outside
– full circle with movers running around the inside
– polygon, circle segments connected with straight sections
– step- and S-shaped track layouts
– rounded-off rectangle with a freely selectable size
AT2025
AT2020
AT9025
www.beckhoff.com/AT2000
www.beckhoff.com/AT9000
AT9025
AT9020
AT9020
News | Motion
XTS mover with 12 rollers
The AT9012 mover is optimised for applications that require a highly rigid guidance.
The rollers of the mover are not pre-loaded. In contrast to the AT9011 mover with
six rollers, the AT9012 mover has twelve rollers. It uses a set of six rollers for running
on straight sections and a further set of six rollers for optimised running through the
curve of the AT9050-0500 rail.
www.beckhoff.com/AT9012
14
Product announcement
For availability status of the new products see Beckhoff website at: www.beckhoff.com
